ADC11AU
Analogue to Digital Audio Converter (ADC)
- ADC (Analogue to Digital Audio Converter) converts analogue left / right stereo audio input to both S/PDIF optical and coaxial digital PCM outputs
- Both optical digital and coaxial digital output simultaneously
- Converts to 16-bit 48kHz digital audio
- Plug and play solution
Our ADC11AU is designed to convert left / right analogue stereo audio into either coaxial or optical digital.
Both digital outputs are simultaneous so audio can be distributed to multiple locations.
The ADC11AU converts to 16-bit 48kHz digital audio for enhanced sound reproduction.
| Audio Input Connectors: | 2 x Analogue stereo left / right (RCA) |
|---|---|
| Audio Output Connectors: | 1 x Optical (SPDIF) & 1 x RCA (SPDIF) |
| Product Dimensions (W x D x H): | 65 x 55 x 25mm (with connections) |
| Product Dimensions (W x D x H): | 55 x 55 x 25mm (without connections) |
| Product Weight: | 0.1kg (excluding accessories) |
| Carton / Box Dimensions (W x D x H): | 165 x 110 x 90mm |
| Shipping Weight: | 0.3kg |
| Operating Temperature: | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature: | -4°F to 140°F (-20°C to 60°C) |
| Power Supply: | 5V/1A DC, barrel type connector |
| Mounting Kit | Included |
